ECOPLAST V-SR - TECHNONICOL

Description of material

Three-layer waterproofing membrane based on high-quality plasticized polyvinylchloride (PVC). It is stabilized against UV-radiation through the use of TRI-P® system. Appearance: The surface is embossed, the top layer is light-gray (approximately RAL 7035); the bottom layer is charcoal-gray. ECOPLAST V-SR is an unreinforced PVC-membrane. It is used for manufacturing elements for strengthening and interfacing to various roofing structures, such as pipes, funnels, and masts.

Method of application

PVC-membrane ECOPLAST should be installed in one layer and is welded using hot air produced by automatic equipment. Contact with all materials containing bitumen, grease, tar, oils or solvents should be avoided. Direct contact with polymeric materials made of polystyrene foam (EPS, XPS), polyisocyanate (PIR) or phenol-containing foams (PF) which can significantly affect the properties of the material and accelerate its aging is not allowed.

Temperature limitations for installation:
– Base temperature: min -20°C/max +50°C;
– Air temperature: min -15°C/max +50 °C.

Storage

Rolls should be stored horizontally on pallets in their original packing, in a place protected from direct sunlight, rain and snow. Storage in two stages with use of rigid spacers is allowed. When observing storage condition limitations the service life is unlimited.

Specifications:

Property ECOPLAST V-SR
Type of polymer PVC
Type of reinforcement unreinforced
Thickness, mm 1,5
Strength at maximum stress, MPa > 14
Specific elongation when broken, % > 200
Water absorption by weight no more than, % 0,1
Bend point on R=5 mm beam, °C -40
Static puncture resistance, 250N х 24 h Watertightness test is passed
Flammability group G4
