CHNOROOF V

ТЕCHNOROOF V

Application areas

Used in civil and industrial construction as a heatinsulation layer for new construction and reconstruction of various buildings and structures. The slabs are designed to be used as the top heat-insulation layer in coverings made of reinforced concrete or metal profile-shaped flooring with roof cladding of roll-fed and mastic materials, including without protective underlayments. Recommended to be applied in combination with TECHNOROOF N and/or TECHNOROOF slabs.

Description of material

TECHNOROOF V are nonflammable, waterproofing, heat- and sound insulating slabs made of basalt rock stonewool with a low-phenol binder.

Storage

The slabs must be stored in covered warehouses. Storage under an awning protecting the slabs from atmospheric precipitation is permitted. slabs during storage should be laid in containers or in piles on pallets or linings. The piling height during storage should not exceed 2 m.



Types of material

    TECHNOROOF V50

    TECHNOROOF V60

    TECHNOROOF V70


Basic physical and mechanical properties

PropertyTECHNOROOF V50TECHNOROOF V60TECHNOROOF V70
Compression strength at 10% deformation, kPa, not less than50 60 70
Flammability gradeNG NG NG
Thermal conductivity, W/m*C 100,036
250,038 0,038 0,040
A0,043 0,041 0,043
B0,046 0,043 0,045
Vapor permeability, mg/(m*h*Pa), not less than0,3 0,3 0,3
Interlaminar strength, kPa, not less than15 15 15
Humidity by weight, %, no more than0,5 0,5 0,5
Water absorption by volume, %, no more than1,5 1,5 1,5
Content of organic substances, %, no more than4,5 4,5 4,5
Density, kg/m3155185 165-195 175205
Length, mm 1000, 1200 1000, 1200 1000, 1200
Width, mm 500, 600 500, 600 500, 600
Thickness (with increments of 10 mm), mm40-50 40-50 40-50
